Product Overview:
The LE-8-GB20120 is a heavy-duty, multi-slot aluminum extrusion plate designed for high-stability industrial applications. Measuring 20mm in height and 120mm in width, this profile functions as a modular "breadboard" or workbench surface.
Engineered from 6063-T5 aluminum alloy, it features multiple standard 8mm T-slots spaced at 20mm intervals, allowing for the secure mounting of jigs, fixtures, and automated components across a wide surface area. Its robust weight of 3.07kg/m ensures maximum rigidity and vibration damping for precision tasks.
Technical Specifications:
Model number: LE-8-GB20120
Material: 6063 T5 Aluminum Alloy
Surface: Silver anodised
Size: 20x120mm
Weight: 3.07kg/m
Length: 50-6000mm/pc
Key Performance Features:
High Load Capacity: The 20mm thickness and internal reinforcement ribs provide superior flatness and structural strength for heavy-duty workbench tops.
Precision Multi-Slotting: Five parallel 8mm T-slots on the top surface enable flexible, repeatable positioning of industrial hardware.
Seamless Integration: The side slots (8.4mm) allow multiple 120mm plates to be joined side-by-side to create large-scale modular work surfaces.
Industrial Grade Finish: The silver anodized surface offers excellent wear resistance and protection against oxidation in factory environments.
Primary Applications:
CNC & Automation: Base plates for CNC routers, laser engravers, and 3D printers.
Industrial Workstations: Precision assembly tables, laboratory desks, and inspection stations.
Tooling & Fixturing: Modular mounting plates for pneumatic clamps and robotic arm bases.
Machine Enclosures: Heavy-duty flooring and structural wall panels for industrial cells.
Manufacturing & Wholesale Services:
As an industry-leading manufacturer, we specialize in high-volume supply for industrial distributors and OEM partners.
Custom Length Cutting: Precision sawing to your exact project requirements.
Advanced Processing: We offer secondary CNC machining, including hole tapping and counter-boring.
B2B Logistics: Optimized packaging and global shipping solutions for bulk structural aluminum orders.
Profile View
Technical Drawing
